Submarine Detection and Monitoring: Open-Source Tools and Technologies
Nicknamed the “Silent Service,” submarines are considered the most survivable
nuclear weapons-delivery platform. They can stay submerged for weeks or even months at a time, and move relatively undetected while on patrol. The
United States,
Russia,
China,
North Korea,
India, and
Pakistan have or are developing submarines capable of carrying nuclear weapons systems. An equal number of countries are developing and testing new nuclear-armed
submarine-launched ballistic and
cruise missiles. [1] Such programs have already had a negative impact on stability in several areas of the globe. For example, the United States, its
NATO allies, and Russia have ramped up Cold War-esque cat-and-mouse submarine hunts in the North Atlantic. [2] Of additional concern is the submarine arms race occurring between India and Pakistan, as well as North Korea’s pursuit of diesel-electric ballistic missile submarine (SSB) capabilities. [3]
Given the integral
deterrence role submarines play in the relationships between
nuclear-armed countries, understanding the tools and technologies available for submarine monitoring is strategically important. Advancements in submarine detection have the potential to affect the survivability of submarines as nuclear delivery platforms. Submarine detection and monitoring was traditionally the exclusive domain of highly classified military units specializing in naval anti-submarine warfare (ASW). Military ASW employs technologies such as magnetic anomaly detectors (MAD), which detect tiny disturbances to Earth’s magnetic field caused by metallic submarine hulls, passive and active sonar sensors that use sound propagation to detect objects underwater, as well as radar and high-resolution satellite imagery to detect surfaced submarines. Recent advances in commercial tools and technologies now give open-source researchers some ability to monitor submarine fleets. With commercial satellite imagery, synthetic aperture radar (SAR), hydro-acoustic sensors, and even social media analysis, open-source researchers can better understand the size and composition of countries’ submarine fleets, monitor construction of submarines and submarine bases, and potentially learn about patrol patterns and behaviors.
Detecting Submarines by
JamesMartinCNS on
Sketchfab
Explore further with this 3D model that highlights parts of submarines vulnerable to detection by social media, satellite imagery, and other sensors.
Commercial Satellite Imagery
Readily accessible high-resolution commercial satellite imagery is one of the most important tools for open-source analysis of submarine activity. Imagery enables researchers to monitor naval shipyards and bases for activity visually, such as those in China and North Korea.
For example, over the years, researchers have used satellite imagery to glean important information about China’s efforts to expand and modernize its fleet of nuclear submarines. In 2007, just as several of China’s new Jin-class (Type 094) SSBs were commissioned, Federation of American Scientists analyst Hans Kristensen began using Google Earth imagery to count the number of operational Jin-class submarines at various bases and shipyards around the country, and later to study the expansion of China’s submarine infrastructure (a network of shipyards, naval bases, underground facilities for missile storage, and submarine demagnetization facilities). [4] Imagery of construction at Longpo Naval Base—the home of China’s southern SSBN fleet—revealed interesting clues about China’s
SSBN program. For example, Kristensen observed the installation of China’s first submarine demagnetization facility, which strips submarine hulls of residual magnetic fields, pointing to Chinese efforts to
deploy less detectable submarines. [5]
Catherine Dill of the Center for Nonproliferation Studies (CNS) published an article revisiting efforts to count China’s operational Jin-class submarines, but unlike Kristensen, she did so using high frequency satellite imagery from Planet Labs. [6] High frequency imagery has revolutionized open-source analysis because it is characterized by a high revisit rate. Often, Planet Labs prioritizes frequent imaging of the same sites (up to twice daily) to enable rapid change detection, as well as comparison of images across multiple sites over the same time periods. Dill captured images of two critical Chinese submarine facilities—the Bohai shipyard and the Longpo Naval Base—on the same day. This enabled her to count Chinese SSBNs more accurately; when using images from different dates, there is a risk of double counting or other errors.
Two Jin-class submarines at the Bohai Shipyard, November 16, 2018. Image courtesy of Catherine Dill and © 2018 Planet Labs, Inc.
Three Jin-class submarines at Longpo Naval Base, November 16, 2018. Image courtesy of Catherine Dill and © 2018 Planet Labs, Inc.
North Korea maintains one of the largest submarine fleets in the world, estimated at between 64 and 86 submarines. The fleet is comprised primarily of conventionally-armed submarines; however, satellite imagery analysis in recent years has uncovered North Korean efforts to build a class of diesel-electric SSBs and
submarine launched ballistic missiles (SLBMs). [7] In 2014, open-source analysts spotted North Korea’s first Gorae-class (aka Sinpo-class) ballistic missile submarine at the Sinpo South Naval Shipyard. [8] At the same time, analysts watched the development and testing of a solid-fueled SLBM that could potentially arm Gorae-class submarines. [9]
Synthetic Aperture Radar (SAR)
Synthetic aperture radar (SAR) is a type of space-based imaging that uses radar echoes to create very high resolution 2- or 3-dimensional representations of landscapes, bodies of water, buildings, and other objects. [10] SAR sensors can pick up tiny changes to landscapes—such as vehicular and foot traffic—that optical sensors cannot detect. SAR imagery first became commercially available in 1995, however companies did not launch high-resolution SAR sensors until 2007. It’s relative newcomer status in the commercial sector means it is less accessible than optical imagery and often prohibitively expensive. [11]
SAR images of the nuclear test site at Punggye-ri showing the subsidence of Mount Mantap due to North Korea’s sixth nuclear test. Images source: Airbus Defence and Space, © DLR e.V. 2017 and © Airbus Defence and Space GmbH 2017.
SAR sensors routinely image the ocean for a variety of environmental, scientific, and law enforcement applications. SAR sensors can also detect the wakes of large surface ships. However, SAR’s ability to detect submarine wakes for anti-submarine warfare (ASW) purposes remains inconclusive.
SAR’s ability to enable analysts to detect even tiny changes makes the technology potentially useful for monitoring submarine construction at naval shipyards. For example, SAR imagery could help analysts to monitor North Korea’s Sinpo South Naval Shipyard, and any construction on North Korea’s expanding SSB fleet, by imaging materiel movement. Additionally, SAR sensors could be used to monitor China’s Bohai for frequent updates on the construction of additional Jin-class SSBNs.
Hydroacoustic Monitoring
Submarines must operate quietly in order to evade enemy sensors because water is a highly efficient conductor of sound. [12] The main source of noise from a submarine comes from its propulsion system. Thus, the design and quality of the propeller blades matter greatly in ensuring the survivability of a country’s sea-based nuclear
deterrent. [13] China’s Jin-class SSBN is reportedly very noisy, providing one possible reason why Chinese submarines rarely stray from coastal to deeper waters. [14] Countries like the United States and China have built networks of hydroacoustic sensors, which use sonar technology to detect submarines that navigate close to their coastal borders and strategic military locations. [15]
Click map for full-view
Map of hydroacoustic monitoring stations in the CTBTO’s international monitoring system (IMS). Map source: Preparatory Commission for the Comprehensive Nuclear Test Ban Treaty Organization, www.ctbto.org/map.
Traditionally, hydroacoustic monitoring has been the domain of national governments. However, in the civilian and scientific sector, the
Comprehensive Nuclear Test Ban Treaty Organization (CTBTO) operates a network of eleven hydroacoustic monitoring stations as part of the International Monitoring System (IMS) for detecting nuclear explosions. The data collected by the CTBTO’s hydroacoustic stations is accessible, by request, for research purposes such as tracking whale migration patterns and developing tsunami warning systems. [16] In late 2017, IMS hydroacoustic data was used to locate the last known position of the
ARA San Juan, an Argentine submarine that disappeared and sadly sank off the coast of Argentina. [17] Open-source researchers could use similar data to isolate the acoustic signatures of submarines and subsequently assess their movements. Analysts could also use this data to analyze SLBM tests by North Korea and other countries developing SLBMs. While open-source researchers have used data from IMS
infrasound stations (which track sound waves undetectable to the human ear) to monitor missile and rocket launches on land, hydroacoustic data has not been utilized in a similar fashion. [18]
Social Media
The rise of social media through platforms such as Facebook, Twitter, Snapchat, and Instagram, as well as crowd-sourcing websites (e.g.,
www.liveuamap.com) and fitness trackers (e.g., Strava), has made maintaining operational security far more difficult for militaries. In recent years, a number of seemingly harmless Tweets and Instagram pictures have revealed themselves as major security breaches. [19] In January 2018, a student at Australian National University discovered that user activity posted on Strava, a fitness app that allows individuals to map their running and biking routes, had unwittingly exposed the locations and perimeters of sensitive military facilities around the world, as well as so-called “patterns of life” of military personnel stations at such facilities. [20] Among the facilities profiled was HM Naval Base Clyde in Faslane, Scotland, where the United Kingdom’s nuclear submarine force is berthed. Pictures posted on Twitter show clear heat signatures around the base’s perimeter, indicating either a running route or perimeter patrol. [21] Potential “patterns of life” risks with naval personnel include identifying a submariner on
Strava and then using their logged exercise locations to map SSBN movements.
Twitter post of Strava heat map data logged around HM Naval Base Clyde, the home of the U.K.’s SSBN fleet.
“Patterns of life” research isn’t specific to fitness trackers—a simple scan of other social media platforms shows just how much material open-source researchers can access for similar analyses. Naval personnel tend to have active digital lives, much like their civilian counterparts. On Instagram, a simple queries result in images and videos taken by members of various navies while in home or foreign ports. If someone were to tag their location while in full uniform with identifying patches exposed, that could be enough information to identify what ship, surface or submarine, that individual is on, as well as its movements.
Interestingly, searches on Twitter and Instagram reveal a large number of individuals who “sub spot” as a hobby. One individual monitors military vessels, including submarines, that transit the Bosphorus Strait in Turkey. [22] Once, a Dutch Naval Commander tweeted a picture of a Russian Krasnodar submarine after it passed his ship in the Bosphorus. Resulting analysis deemed the submarine was likely headed to the port of Tartus, Syria, to aid Russian military operations in the country. [23] Other accounts publish images or videos taken by average citizens who just happen to see a giant submarine cruise past them. Still others repost digital media related to submarines published by military accounts.
A photo taken by a Dutch Naval Commander of a Russian Krasnodar submarine as it passes his ship in the Bosphorus Strait in Turkey.
Summary
Commercial satellite imagery, SAR, social media, and hydroacoustic monitoring are just a few of many new tools that have transformed open-source analysis in the
nonproliferation field. As the United States, Russia, China, North Korea, India, and Pakistan build up and modernize the sea-based leg of their nuclear arsenals, these tools will remain important to open-source assessments of their programs.
